Parameter Value
VLANID
[1-4094]
If VLAN enabling is set to Enabled, this parameter takes
the value of uservlan that is specified when you configure a
service flow for the Internet access service on the OLT.
Binding item LAN1 and LAN2: PCs connected to ports LAN1 and LAN2
can simultaneously access the Internet.
Mode Bridge: PCs access the Internet through PPPoE dialup.
c. Click OK.
3. Restart the HGW.
Choose Management > Device Management and click Restarting the Device.
----End
10.6.2.6 Configuring the Voice Service
The OLT is connected to the remote ONU through a GPON port to provide users with the IP-
based high-quality and low-cost VoIP service.
Prerequisites
l The SIP interface data and POTS user data corresponding to the MG interface have been
configured on the SIP server.
l The connection between the OLT and the SIP server is set up. The OLT can ping the IP
address of the SIP server successfully.
l The ONU has been added to the OLT. For details, see 10.6.1.3 Adding an ONU to an
OLT.
l HGWs have different models and appearances but their configuration procedures are
similar. This topic uses the HG255 that uses LAN for upstream transmission as examples.
l The IADs use SIP as the voice protocol.
Data Plan
Item Data
ONU line profile Profile name: fttd
T-CONT ID: 4
GEM port ID: 12
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 10 FTTD Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
800
