Huawei SmartAX MA5608T User Manual

5 Configuration Example of MSTP
Subtending Network
About This Chapter
This topic describes how to configure the integrated services on the MA5600T/MA5603T/
MA5608Ts in the MSTP ring network.
5.1 MSTP Networking
This topic describes the typical networking in the MSTP mode.
5.2 MSTP Dataplan
This topic provides the data plan for the example RSTPMSTP network.
5.3 Configuring MA5600T/MA5603T/MA5608T-1
This topic describes how to configure MA5600T/MA5603T/MA5608T-1.
5.4 Configuring MA5600T/MA5603T/MA5608T-2
This topic describes how to configure MA5600T/MA5603T/MA5608T-2.
5.5 Configuring MA5600T/MA5603T/MA5608T-3
This topic describes how to configure MA5600T/MA5603T/MA5608T-3.
5.6 Configuring MA5600T/MA5603T/MA5608T-4
This topic describes how to configure MA5600T/MA5603T/MA5608T-4.
5.7 Configuring MA5600T/MA5603T/MA5608T-5
This topic describes how to configure MA5600T/MA5603T/MA5608T-5.
5.8 Verification
All services configured on all DSLAMs run in the normal state.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
5 Configuration Example of MSTP Subtending Network
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
439

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
