Figure 14-16 Networking diagram of Ethernet base station access service
FE/GE
FE/GE
eNodeB
ONU
OLT
RNC
ETH
GE/10GE
NodeB
FE/GE
ONU
RNC
FE/GE
CX600
L2/L3 VPN
ETH
GE
GPON QinQ
PSN
14.4.3.2 Configuration Process
The following figure shows the configuration process for Ethernet base station access service
(in QinQ VLAN mode).
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 14 FTTM Configuration (Base Station Access)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1433
