Huawei SmartAX MA5608T - Configuring Satop Connections between OLTA and ONU

huawei(config)#vlan 300 smart
huawei(config)#port vlan 300 0/2 1
----End
13.3.6.4 Configuring SAToP Connections between OLT_A and ONU
Data Plan
Configurati
on Item
Data
EDTB (OLT) Port: 0/5/0
Board IP address: 10.10.50.10
Board MAC address: dynamically obtained (remark 1)
Local UDP port number: 50048 (remark 2)
E1 port
(ONU)
Board IP address: 10.10.50.20
Board MAC address: dynamically obtained (remark 1)
UDP port number: 50048 (remark 2)
VLAN SVLAN: 300
Remark 1: MAC address configuration modes (statically configured or dynamically obtained)
at two ends must be consistent to establish a SAToP connection. It is recommended that MAC
addresses be dynamically obtained, which facilitates configuration and maintenance.
Remark 2: The UDP port cannot be a port that is widely used in the industry and for specific
services. For example, port 80 is used for HTTP service. The dynamic and private ports are
recommended.
Procedure
Step 1 Configure EDTB board attributes.
Set the board working mode to SAToP.
huawei(config)#interface edt 0/5
huawei(config-if-edt-0/5)#board workmode satop
Configure the access mode and frame format.
l E1 access:
huawei(config-if-edt-0/5)#tdm access-mode E1
Configure the IP address of the E1 port on the EDTB board.
huawei(config)#interface edt 0/5
huawei(config-if-edt-0/5)#set ip-address 10.10.50.10
huawei(config-if-edt-0/5)#quit
Step 2 Create a SAToP connection.
Create TDM VCL 10.
