huawei(config)#traffic table ip index 8 cir off priority 4 priority-policy
local-setting
2. Configure the VLAN and service flows.
Table 12-48 Data plan
VLAN Plan VLAN Translation Policy
Single VLAN tag
l S-VLAN ID: 1100
l VLAN type: smart
l VLAN attribute: common
l C-VLAN: 2001
The ONU adds CVALN tags to packets:
untagged <-> C-VLAN tag.
The OLT implements VLAN translation:
C-VLAN tag <-> S-VLAN tag.
Configure the mapping between a GEM port and a VLAN. The service flow of user VLAN
2001 is mapped to GEM port 13 in the ONU line profile.
huawei(config)#ont-lineprofile gpon profile-name ftto_line
huawei(config-gpon-lineprofile-1)#gem mapping 13 4 vlan 2001
huawei(config-gpon-lineprofile-1)#commit
huawei(config-gpon-lineprofile-1)#quit
Create a service VLAN and add an upstream port to it. Add upstream port 0/19/0 to VLAN
1100.
huawei(config)#vlan 1100 smart
huawei(config)#port vlan 1100 0/19 0
Create service flows. Set the S-VLAN to 1100, GEM port ID to 13, and C-VLAN to 2001,
and use traffic profile 8. Set the VLAN translation policy to Translate. The C-VLAN 2001
of the ONU is translated to S-VLAN 1100.
huawei(config)#service-port 3 vlan 1100 gpon 0/1/0 ont 1 gemport 13
multi-service user-vlan 2001 tag-transform translate rx-cttr 8 tx-cttr 8
huawei(config)#service-port 4 vlan 1100 gpon 0/1/0 ont 2 gemport 13
multi-service user-vlan 2001 tag-transform translate rx-cttr 8 tx-cttr 8
3. Save the data.
huawei(config)#save
Step 2 The ONU does not need to be configured.
----End
12.4.2.11 Configuring Link Aggregation, Congestion Control, and Security Policy
Service reliability is improved by configuring uplink aggregation and priority scheduling policy
for queues in global configuration mode, and service security is improved by configuring
security policy in global configuration mode.
Context
In link aggregation, multiple uplink Ethernet ports are aggregated into a group to increase
bandwidth and reliability of uplinks of the OLT. You are advised to configure link aggregation.
