huawei(config-if-power4875l-0)#power temperature-off battery-off-state permit
battery-off-temperature 53
huawei(config-if-power4875l-0)#power environment temperature 68 -5 80 -20
huawei(config-if-power4875l-0)#power outside-digital 3 available-level low-level
name SPD digital-alarm 20
huawei(config-if-power4875l-0)#power outside-digital 4 available-level high-level
name Smoke digital-alarm 15
huawei(config-if-power4875l-0)#power outside-digital 5 available-level low-level
name HEX digital-alarm 13
huawei(config-if-power4875l-0)#power outside-digital 6 available-level low-level
name MDF-door digital-alarm 9
huawei(config-if-power4875l-0)#display power system parameter
huawei(config-if-power4875l-0)#display power environment parameter
huawei(config-if-power4875l-0)#display power alarm
huawei(config-if-power4875l-0)#quit
huawei(config)#save
1.3.16.6 Configuring the Environment Monitoring Parameters of the GEPS4845
This topic describes how to configure the environment monitoring parameters of the GEPS4845
through the CLI.
Mapping Between Monitoring Parameters and Device Ports
Table 1-31 describes the mapping between the monitoring parameters displayed on the sensor
transfer box.
Table 1-31 Mapping between the monitoring parameters displayed on the host and the ports on
the sensor transfer box
Monitoring Parameter
Displayed on the Host
Device Port Application in the F01D500
Cabinet
Digital 0 JTD1 Not connected by default, used to
add a user-defined monitoring
digital parameter
Digital 1 JTD2 Not connected by default, used to
add a user-defined monitoring
digital parameter
Digital 2 JTD3 Not connected by default, used to
add a user-defined monitoring
digital parameter
Digital 3 JTD4 surge protector (SPD)
Digital 4 JTD5 Smoke sensor
Digital 5 JTD6 Heat exchanger
Digital 6 JTD7 Door status sensor of the MDF
compartment
Door alarm JTM1 Door status sensors of the device
compartment and heat exchanger
compartment
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 1 Commissioning
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
103

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
