Huawei SmartAX MA5608T User Manual

As shown in the preceding figure, Type C single homing protecting is configured for optical
fiber links between the OLT and ONU.
– The ports on the GPON service board are 0/3/1 and 0/3/2.
– The link at port 0/3/1 is the working link.
– The link at port 0/3/2 is the protection link.
– The ONU ID is 1.
– The ONU is authenticated by serial number (SN). The SN of the ONU is
32303131B39FD641 and the management mode is SNMP.
– The ID of the line profile bound to the ONU is 10.
huawei(config)#interface gpon 0/3
huawei(config-if-gpon-0/3)#ont add 1 1 sn-auth 32303131B39FD641 snmp ont-
lineprofile-id 10
huawei(config-if-gpon-0/3)#ont add 2 1 protect-side
huawei(config-if-gpon-0/3)#quit
huawei(config)#protect-group protect-target gpon-uni-ont workmode portstate
huawei(protect-group-1)#protect-group member port 0/3/1 ont 1 role work
huawei(protect-group-1)#protect-group member port 0/3/2 ont 1 role protect
huawei(protect-group-1)#protect-group enable
huawei(protect-group-1)#quit
----End
14.4.2.9 Configuring ONU SAToP Connections
This topic describes how to configure a SAToP connection of the IP+UDP encapsulation type
and a service VLAN to enable packets of base stations to be encapsulated on ONUs as Ethernet
packets and then forwarded based on VLANs and MAC addresses.
Data Plan
Configurati
on Item
Data
EDTB (OLT) Port: 0/5/0
Board IP address: 10.10.50.10
Board MAC address: dynamically obtained (remark 1)
Local UDP port number: 50048 (remark 2)
E1 port
(ONU)
Board IP address: 10.10.50.20
Board MAC address: dynamically obtained (remark 1)
UDP port number: 50048 (remark 2)
VLAN SVLAN: 300
Remark 1: MAC address configuration modes (statically configured or dynamically obtained)
at two ends must be consistent to establish a SAToP connection. It is recommended that MAC
addresses be dynamically obtained, which facilitates configuration and maintenance.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
14 FTTM Configuration (Base Station Access)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1428

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
