Parameter Value
VLAN
enabling
Enable VLAN tags are added to upstream packets.
NOTE
When BTV service flows are created on the OLT, the value is
Disable if uservlan is untagged and the value is Enable if
uservlan is tagged.
VLANID
[1-4094]
VLAN ID corresponding to the user VLAN value for BTV
service flows created on the OLT. In this example, set this
parameter to 43.
Binding item LAN3
Mode Bridge
DHCP
transparent
transmission
Enable
c. Click OK to save the settings.
3. Restart the HGW.
Choose Management > Device Management and click Restarting the Device.
----End
10.6.1.11 Configuring the VoD Service
The OLT is connected to the remote bridging ONU through a GPON port to provide users with
the VoD service.
Prerequisites
l The OLT is connected to the BRAS and the program source.
l The VLAN of the LAN switch port connected to the OLT is the same as the upstream
VLAN of the OLT.
l The ONU has been added to the OLT. For details, see 10.6.1.3 Adding an ONU to an
OLT.
l A VDSL2 port has been activated. For details, see 10.6.1.4 Configuring a VDSL2 User
Port.
Data Plan
Item Data
ONU line profile Profile name: fttd
T-CONT ID: 4
GEM port ID: 13
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 10 FTTD Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
779
