Huawei SmartAX MA5608T User Manual

Scenario IP Address Planning
Ethernet base
station access
service (in QinQ
VLAN mode)
No IP addresses need to be planned because the OLT and ONUs
provide Layer 2 transparent channels.
14.2.2 Principle of VLAN Data Plan
VLAN planning for the base station access service covers planning of VLANs and VLAN
translation policies in different networking scenarios.
VLAN and VLAN Translation Policy
Scenario VLAN Planning VLAN Translation
ONU OLT
E1 base station
access service
(in Native TDM
mode)
Use a reserved CVLAN
(starts from 4000).
NOTICE
A reserved CVLAN cannot be
used for Ethernet services on
ONUs.
N/A N/A
E1/T1 base
station access
service (in
SAToP mode)
Plan a global VLAN on the
OLT and ONUs, which
cannot conflict with other
service VLANs.
N/A N/A
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 14 FTTM Configuration (Base Station Access)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1367

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
