15.1.2 Networking Scenarios and Hardware Configurations
(GPON)
This section describes networking scenarios of a distributed cable modem termination system
(D-CMTS) when the D-CMTS works as a GPON remote extended frame and D-CMTS's
hardware configurations.
Networking Scenarios and Hardware Configurations
Networking
Scenario
Description OLT Device ONU Device
Home service
networking
In home service networking,
a distributed cable modem
termination system (D-
CMTS) connects to cable
modems (CMs) at user homes
through radio frequency (RF)
ports and provides home
services for users, including
the cable TV (CATV)
service, Internet access
service, VoD service,
broadband TV (BTV)
service, and PacketCable
service.
l MA5603T or
MA5600T:
– Control
board:
SCUV
– Service
board:
GPMD
– Upstream
interface
board:
SPUF
l MA5608T:
– Control
board:
MCUE
– Service
board:
GPMD
MA5633
L2VPN
enterprise
service
networking
In L2VPN enterprise service
networking, a distributed
cable modem termination
system (D-CMTS) connects
to cable modems (CMs)
through radio frequency (RF)
ports, and the CMs connect to
switches or routers to provide
the L2VPN service for users.
Wireless
local area
network
(WLAN)
hotspot radio
backhaul
service
networking
In wireless local area network
(WLAN) hotspot radio
backhaul service networking,
a distributed cable modem
termination system (D-
CMTS) connects to cable
modems (CMs) through radio
frequency (RF) ports. A CM
connects to wireless access
points (APs) to provide
wireless fidelity (Wi-Fi)
access for users.
