huawei(config)#interface edt 0/2
huawei(config-if-edt-0/2)#clock-work 0 system //The clock of the E1 port is
the system clock.
l For SHDSL access:
huawei(config)#interface edt 0/2
huawei(config-if-edt-0/2)#tdm-clock clock-recovery-mode 0 retiming
----End
Follow-up Procedure
After all the configurations are performed successfully, the related information about the CESoP
connection can be queried by running the display cesop-connect command on the ONU.
huawei(config)#display cesop-connect all
------------------------------------------------------------------------------
ID PORT VCL ENCAP REMOTEMAC REMOTEIP LOCALUDP REMOTEUDP VLAN
ID TYPE /RXPWLABEL /TXPWLABEL
------------------------------------------------------------------------------
0 0/1 /0 0 MPLS e024-7f98-a21b - 9343 8192 TOE
------------------------------------------------------------------------------
Total: 1
14.4.6.4 Configuring Clock Synchronization
In this scenario, network-wide clock synchronization is implemented through synchronous
Ethernet clocks.
Prerequisites
l The clock daughter board CKMC/CKMD of the SCU control board is in position.
l The Ethernet upstream board is the GICK/GSCA (GE port) or X2CS/SPUF (10GE port)
board.
l The upstream MAN PSN of the OLT supports Synchronous Ethernet.
Data Plan
Item Data
Ethernet upstream
board
Port: 0/19/0
NOTE
The SPUF board exclusively occupies a service slot. This topic uses the GIU
upstream board as an example.
Procedure
l Configure the OLT-side clock.
1. Configure a system clock source.
Use the Ethernet line clock input from GIU port 0/19/0 as the system clock. Set the
index of the system clock to 0 and priority to 0 (highest priority).
huawei(config)#clock source 0 0/19/0
huawei(config)#clock priority system 0
2. Query the configurations and status of the system clock source.
