huawei(config-if-smu-1)#quit
huawei(config)#save
1.3.16.8 Configuring the Environment Monitoring Parameters of the ETP4890
This topic describes how to configure the environment monitoring parameters of the ETP4890
through the CLI.
Mapping Between Monitoring Parameters and Device Ports
The ETP4890 monitoring scheme can be used in the F01D500 cabinet. Table 1-36 describes
the mapping between the monitoring parameters displayed
NOTE
Before adding a user-defined analog or monitoring digital parameter, make sure that the port corresponding
to this parameter is properly connected to an environment monitoring cable.
Table 1-36 Mapping between the monitoring parameters displayed on the host and the ports on
the sensor transfer box
Monitoring Parameter
Displayed on the Host
Device Port Application in the F01S300
Cabinet
Digital 0 JTD1 Not connected by default, used to
add a user-defined monitoring
digital parameter
Digital 1 JTD2 Not connected by default, used to
add a user-defined monitoring
digital parameter
Digital 2 JTD3 Not connected by default, used to
add a user-defined monitoring
digital parameter
Digital 3 JTD4 Surge protector (SPD)
Digital 4 JTD5 Not connected by default, used to
add a user-defined monitoring
digital parameter
Digital 5 JTD6 Heat exchanger
Digital 6 JTD7 Door status sensor of the MDF
compartment
Door alarm JTM1 Door status sensors of the device
compartment and heat exchanger
compartment
Wiring alarm JTP1 MDF
Battery Tem VBTEM2 Battery temperature sensor
environment Tem VTEM2 Environment temperature sensor
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 1 Commissioning
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
115
