1-15> }:
Command:
display nac configuration master
-----------------------------------------------------------------------------
Frame ID/Slot ID/Port ID : 0/3/0
VLAN : 8
VLAN priority : 3
IP address : 192.168.50.2
Mask : 255.255.255.0
Gateway : 192.168.50.254
Snmp-profile-id : 64
Snmp-profile-name : snmp-profile_64
-----------------------------------------------------------------------------
Total: 1
Step 2 Check whether the management channel between the OLT and the D-CMTS is available.
Upon power-on, the D-CMTS exchanges data with the OLT to obtain the management
parameters.
l Run the ping 192.168.50.2 command on the OLT to check whether the D-CMTS can
communicate with the OLT. If the OLT can receive Internet Control Message Protocol
(ICMP) ECHO-REPLY packets sent from the D-CMTS, the D-CMTS is connected to the
OLT.
l Run the telnet command on the OLT to remotely log in to the ONU from the OLT to perform
the configuration. The user name is root and the password is mduadmin.
----End
16.3.1.8 Configuring a Service Channel Between an OLT and a D-CMTS
This section describes how to configure a service channel between an optical line terminal (OLT)
and a distributed cable modem termination system (D-CMTS). After the configuration, the
service channel forwards service packets on the D-CMTS based on the planned VLAN and
forwarding policy.
Data Plan
Item Data
High-speed Internet (HSI), VoD,
broadband TV (BTV), or dynamic
PacketCable service
ID of the OLT VLAN (transparently transmitting D-
CMTS packet tags): 100
ID of the D-CMTS VLAN: 100
ID of the common open policy service (COPS)
connection VLAN: 1000
Uplink ports Forwarding Dynamic Host Configuration Protocol
(DHCP) and broadband packets: 0/4/0
Forwarding cable modem (CM) management, VoD,
and multicast packets: 0/5/0
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
16 OptiCable D-CMTS Configuration (MA5633 Working as
a Standalone NE)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1694
