Item Data Remarks
Management profile
of the D-CMTS
ID: 64
Name: snmp-profile_64
SNMP version: SNMPv2c
D-CMTS through the command
line interface (CLI).
Procedure
Step 1 Configure a management channel between the OLT and the D-CMTS.
1. Configure the inband management VLAN and IP address of the OLT.
huawei(config)#vlan 8 smart
huawei(config)#port vlan 8 0/5 0
huawei(config)#interface vlanif 8
huawei(config-if-vlanif8)#ip address 192.168.50.1 24
huawei(config-if-vlanif8)#quit
2. Enable Network Admission Control (NAC) on the OLT.
huawei(config)#nac enable master 0/3 0
3. (Optional) Create an SNMP management profile.
Perform this operation if the D-CMTS is managed through the U2000. Plan an SNMP
management profile on the U2000 and D-CMTS before creating the profile.
huawei(config)#snmp-profile add profile-id 64 profile-name snmp-profile_64 v2c
public
private 192.168.50.55 30000 trapstatus
4. Configure D-CMTS management parameters on the OLT.
huawei(config)#nac config master 0/3/0 slave vlan 8 priority 6 ip-address
192.168.50.2 mask 255.255.255.0 gateway 192.168.50.1 snmp-profile-id 64
Check whether the D-CMTS management parameters have been configured on the OLT.
huawei(config)#display nac configuration master
{ <cr>|frameid/slotid/portid<S><Length 1-255>|frameid/slotid<S><Length
