NOTE
l To configure the data of a single SIP PSTN user, run the sippstnuser add command.
l To configure the data of multiple SIP PSTN users in batches, run the sippstnuser batadd command.
huawei(config)#esl user
huawei(config-esl-user)#sippstnuser batadd 0/3/0 0/3/23 0 telno 83110001
Step 10 Configure call priorities for SIP PSTN users.
huawei(config-esl-user)#sippstnuser attribute set 0/3/0 priority cat2
huawei(config-esl-user)#quit
Step 11 Configure all the PSTN ports to support polarity reversal.
Configure the physical attributes of the PSTN port to which the users belong to support polarity
reversal so that the user supports polarity reversal accounting.
huawei(config)#pstnport
huawei(config-pstnport)#pstnport attribute batset 0/3/0 0/3/23 reverse-pole-pulse
enable
huawei(config-pstnport)#quit
Step 12 Save the data.
huawei(config)#save
----End
11.3.2.11 Configuring Link Aggregation, Congestion Control, and Security Policy
The global configuration of upstream link aggregation and queue scheduling based on priorities
ensures service reliability. The global configuration of security policies ensures service security.
Context
Link aggregation provides a higher bandwidth and uplink reliability for optical line terminals
(OLTs) by aggregating multiple uplink Ethernet ports to one link aggregation group (LAG).
Link aggregation is recommended.
Congestion control places the packets to be sent from a port into multiple queues that are marked
with different priorities. Then, the packets are sent based on queue priorities. Congestion control
is recommended.
Security policies ensure system, user, and service security.
NOTE
Enable a service security function based on the service type. For details, see 11.2.7 Principle of Security Data
Plan.
Procedure
l Configure link aggregation.
The following configurations are used as an example to configure link aggregation:
– Uplink ports 0/19/0 and 0/19/1 are added to a LAG.
– The two ports send packets upstream based on the packets' source MAC addresses.
– The LAG works in Link Aggregation Control Protocol (LACP) static aggregation mode.
huawei(config)#link-aggregation 0/19 0-1 ingress workmode lacp-static
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
915
