Huawei SmartAX MA5608T User Manual

Application
Scenario
VLAN
Plan
VLAN Translation
MDU/GE Remote Extended Subrack OLT/
Master
Subrac
k
FTTB and FTTC
Ethernet cascading
(centralized
management for GE
remote extended
subracks)
l Without HGWs: The extended subrack
maps inner C-VLANs based on user ports
and adds S-VLANs to packets. Ensure that
the C-VLANs of users using the same S-
VLAN do not repeat each other.
l xDSL access using HGWs:
– ATM upstream transmission: The
extended subrack translates PVCs to
C-VLANs (PVC <-> C-VLAN) and
adds S-VLANs to packets. Ensure that
the C-VLANs of users using the same
S-VLAN do not repeat each other.
– PTM upstream transmission:
Untagged upstream packets of HGWs:
The extended subrack maps C-VLANs
based on user ports and adds S-VLANs
to packets. User-VLAN-tagged
upstream packets of HGWs: The
extended subrack translates user
VLANs to C-VLANs (user VLAN <->
C-VLAN) and adds S-VLANs to
packets. Ensure that the C-VLANs of
users using the same S-VLAN do not
repeat each other.
The
master
subrack
transmit
s
packets
transpar
ently.
11.2.4 (Optional) Principle of Vectoring Data Plan
Vectoring data plan includes grouping, the policy for activating a legacy customer premises
equipment (CPE), and line profile planning of a port.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
840

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
