Scenario Description OLT Typical
Configuration
(Main Control Board
+
Service Board
+Upstream Board)
MDU
Configuration
MA5611S-DE48-
A, MA5603T.
11.1.3 Scenario and Hardware Configuration (10G GPON)
The typical 10G GPON FTTB and FTTC networking scenarios and their OLT and ONU
hardware configurations are listed in the table below.
Scenario Description MDU
Configuration
FTTB Networking
(LAN Access
Without HGW)
l The ONU is deployed in the building and
is connected to the user's home through
the category-5 cable.
l The ONU provides FE and POTS ports
for the Internet access and VoIP services.
ONUs applicable to
this scenario:
l MA5616
l MA5822
FTTB/C
Networking (xDSL
Access Without
HGW)
l The ONU is deployed in the building or
street fiber distribution terminal and is
connected to the user's home through the
twisted pair cable.
l The ONU provides xDSL and POTS ports
for the Internet access and VoIP services.
ONUs applicable to
this scenario:
MA5616
FTTB/C+HGW
Networking (ONU
Providing the VoIP
Service)
l The ONU is deployed in the building or
street fiber distribution terminal and uses
LAN or xDSL to connect to the HGW
deployed at user's home. The HGW
provides service access interfaces and the
built-in IAD of the ONU provides the
VoIP service.
l The HGW provides the Internet access
and IPTV services by connecting to the
upstream ONU using LAN or xDSL.
ONUs applicable to
this scenario:
l MA5616
l MA5822
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
821
