Huawei SmartAX MA5608T User Manual

1.3.11.1 Adding a Board Offline
This topic describes how to add a board to an idle slot that is consistent with the board actually
planned beforehand to ensure that the board runs immediately the board is installed in the slot.
Prerequisites
The slot to which a board is added must be idle.
Context
l The boards other than the control board can be added offline.
l After a board is added offline, the board status is displayed as Failed. The board status
becomes normal only when a board of the same type as the board added offline is installed
in the slot. If a board of a different type is installed, the board resets repeatedly due to the
board type mismatch.
Procedure
Step 1 Run the board add command to add a board offline.
NOTE
l The shelf ID and the slot ID of the board added offline must be the same as the actual position.
Otherwise, when the board is installed, the board status cannot be changed to normal.
l The type of the board added offline must be the same as the type of the board installed. Otherwise,
when the board is installed, the board status cannot be changed to normal.
Step 2 Run the display board frameid [ /slotid ] command to query the type of the added board.
----End
Result
The type of the added board is the same as the board type that is planned. When a board is
installed in the slot in which the board is added, the board status is displayed as Normal.
Example
To add a service board GPBD offline in slot 0/2, do as follows:
huawei(config)#board add 0/2 h802gpbd
0 frame 2 slot board added successfully
huawei(config)#display board 0/2
---------------------------------------
Board Name : H802GPBD
Board Status : Failed
---------------------------------------
-------------------------------------------------------------
Port Port min-distance max-distance Optical-module
type (km) (km) status
-------------------------------------------------------------
0 GPON 0 20 -
1 GPON 0 20 -
2 GPON 0 20 -
3 GPON 0 20 -
4 GPON 0 20 -
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
1 Commissioning
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
72

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
