l HSI, VoIP, and CM management services for home users carry the same S-VLAN tag on
a layer 3 network.
l HSI, VoIP, and CM management services for home users carry the different S-VLAN tags
on a layer 2 telecom network. Service types can be identified based on VLANs.
l A D-CMTS identifies the L2VPN enterprise and WLAN hotspot radio backhaul services
by S-VLAN tag.
16.3 Service Configuration on a D-CMTS That Works in GE
Access Mode on a Layer 3 Network
This section describes how to configure services, including home services, L2VPN enterprise
service, and wireless local area network (WLAN) hotspot radio backhaul service, on a distributed
cable modem termination system (D-CMTS) that works in GE access mode on a Layer 3
network. The MA5603T equipped with the SCUV, OPGE, and SPUF boards is used as an
example.
Control Board
SCUV
Interface Board OPGE: 0/3
SPU Board SPUF: 0/4, 0/5
NOTE
When an OPGE board is used, run the network-role command on the OLT to configure the ports on the OPGE
board as cascading ports.
16.3.1 Home Service Networking
In home service networking, an MA5633 connects to cable modems (CMs) at user homes
through radio frequency (RF) ports and provides home services for users, including the cable
TV (CATV) service, Internet access service, VoD service, broadband TV (BTV) service, and
PacketCable service. This section describes how to configure the optical line terminal (OLT)
and the MA5633 to provision the home services.
NOTE
Configuration procedures are the same for IPv6 and IPv4 networks except in "Configure Dynamic Host
Configuration Protocol (DHCP) relay" and "Configure a route". In addition, IPv6 does not support the
function of configuring PacketCable dynamic voice services.
16.3.1.1 Service Requirements and Usage Scenario
Service Requirements
Users require the provisioning of the TV service, Internet access service, VoD service,
broadband TV (BTV) service, and VoIP service. The TV service can be provisioned immediately
after the distributed cable modem termination system (D-CMTS) hardware is connected. This
section only describes how to configure the Internet access service, VoD service, BTV service,
and VoIP service.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
16 OptiCable D-CMTS Configuration (MA5633 Working as
a Standalone NE)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1679
