Step 5 Set the IP address of the gateway for the DHCP domain.
huawei(config)#interface vlanif 100
huawei(config-if-vlanif100)#dhcp domain docsis gateway 10.10.224.1 //Set the IP
address of the gateway for the CM domain to 10.10.224.1.
huawei(config-if-vlanif100)#quit
----End
15.4.2.4 Configuring a Route
This section describes how to implement network communication by configuring a route in
Layer 3 networking with an optical line terminal (OLT). Through the route, packets are
forwarded at Layer 3 between the OLT and its upper-layer devices or servers.
Prerequisites
The upper-layer router of an OLT has been configured.
Data Plan
Table 15-45 Data plan for the Layer 3 interfaces on the network side
Item IP Address
Layer 3 interfaces on the
OLT network side
Forwarding Dynamic Host Configuration Protocol (DHCP)
packets:
l VLAN ID: 2004
l Port number: 0/4/0
l IP address: 11.11.11.10/24
Forwarding cable modem (CM) management packets:
l VLAN ID: 2005
l Port number: 0/5/0
l IP address: 11.11.12.10/24
Layer 3 interfaces
connecting the router to
the OLT
l Forwarding DHCP packets: 11.11.11.11
l Forwarding CM management packets: 11.11.12.11
Upper-layer servers of
the OLT
l DHCP server assigning IP addresses to CMs and media
terminal adapters (MTAs): 192.168.10.10-192.168.10.11
l CM management system: 192.168.20.1
Procedure
Step 1 Create Layer 3 VLAN interfaces on the network side.
1. Create VLANs and configure their uplink ports.
l VLAN 2004 is of the smart VLAN type and used for forwarding DHCP packets. Add
uplink port 0/4/0 to VLAN 2004.
