1-15> }:
Command:
display nac configuration master
-----------------------------------------------------------------------------
Frame ID/Slot ID/Port ID : 0/3/0
VLAN : 8
VLAN priority : 3
IP address : 192.168.50.2
Mask : 255.255.255.0
Gateway : 192.168.50.254
Snmp-profile-id : 64
Snmp-profile-name : snmp-profile_64
-----------------------------------------------------------------------------
Total: 1
Step 2 Check whether the management channel between the OLT and the D-CMTS is available.
Upon power-on, the D-CMTS exchanges data with the OLT to obtain the management
parameters.
l Run the ping 192.168.50.2 command on the OLT to check whether the D-CMTS can
communicate with the OLT. If the OLT can receive Internet Control Message Protocol
(ICMP) ECHO-REPLY packets sent from the D-CMTS, the D-CMTS is connected to the
OLT.
l Run the telnet command on the OLT to remotely log in to the ONU from the OLT to perform
the configuration. The user name is root and the password is mduadmin.
----End
16.3.2.8 Configuring a Service Channel Between an OLT and a D-CMTS
Data Plan
Item Data
L2VPN enterprise service ID of the OLT VLAN (transparently transmitting D-
CMTS packet tags): 200
ID of the D-CMTS VLAN: 200
Uplink ports Port forwarding Dynamic Host Configuration
Protocol (DHCP) and broadband packets: 0/4/0
Port forwarding cable modem (CM) management and
VoD packets: 0/5/0
Procedure
l Configure a channel for the L2VPN enterprise service.
1. Configure an L2VPN service VLAN (S-VLAN).
The following configurations are used as an example to configure an S-VLAN:
– S-VLAN ID: 200
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
16 OptiCable D-CMTS Configuration (MA5633 Working as
a Standalone NE)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1722
