Log in to the ONU from the OLT, and then configure the port signaling mode of E1 port 0/1/0
to UDT and the transmit clock to system.
huawei(config)#interface tdm 0/1
huawei(config-if-tdm-0/1)#port 0 udt system
huawei(config-if-tdm-0/1)#quit
----End
Follow-up Procedure
After all the configurations are performed successfully, the related information about the CESoP
connection can be queried by running the display cesop-connect command on the ONU.
huawei(config)#display cesop-connect all
------------------------------------------------------------------------------
ID PORT VCL ENCAP REMOTEMAC REMOTEIP LOCALUDP REMOTEUDP VLAN
ID TYPE /RXPWLABEL /TXPWLABEL
------------------------------------------------------------------------------
0 0/1 /0 0 MPLS e024-7f98-a21b - 9343 8192 TOE
------------------------------------------------------------------------------
Total: 1
14.4.4.5 Configuring Clock Synchronization
In this scenario, network-wide clock synchronization is implemented through synchronous
Ethernet clocks.
Prerequisites
l The clock daughter board CKMC/CKMD of the SCU control board is in position.
l The Ethernet upstream board is the GICK/GSCA (GE port) or X2CS/SPUF (10GE port)
board.
l The upstream MAN PSN of the OLT supports Synchronous Ethernet.
Data Plan
Item Data
Ethernet upstream
board
Port: 0/19/0
NOTE
The SPUF board exclusively occupies a service slot. This topic uses the GIU
upstream board as an example.
Procedure
l Configure the OLT-side clock.
1. Configure a system clock source.
Use the Ethernet line clock input from GIU port 0/19/0 as the system clock. Set the
index of the system clock to 0 and priority to 0 (highest priority).
huawei(config)#clock source 0 0/19/0
huawei(config)#clock priority system 0
2. Query the configurations and status of the system clock source.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
14 FTTM Configuration (Base Station Access)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1457

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
