Item Data
Phone number 88880000
Procedure
Step 1 Configure the working mode of the ISDN BRA port.
In the BRA port mode, configure the working mode of the ISDN BRA port to P2MP, configure
the activation mode to stable activation, and enable automatic activation.
huawei(config)#braport
huawei(config-braport)#braport attribute set 0/3/1 workmode p2mp autodeactive
enable
huawei(config-braport)#quit
Step 2 Configure the ISDN BRA user data.
huawei(config)#esl user
huawei(config-esl-user)#sipbrauser add 0/3/1 0 telno 88880000
huawei(config-esl-user)#quit
Step 3 Save the data.
huawei(config)#save
----End
Result
After the configuration is completed, two ISDN BRA users of the NT1 connected to port 0/3/1
can make calls successfully.
Configuration File
braport
braport attribute set 0/3/1 workmode p2mp autodeactive enable
quit
esl user
sipbrauser add 0/3/1 0 telno 88880000
quit
save
3.3.9 Example: Configuring the ISDN PRA Service
This topic is applicable to the scenario where the ISDN users are connected to the MA5600T/
MA5603T/MA5608T through the ISDN primary rate interface (PRI).
Prerequisite
l The PSTN user (Phone B in the example network) must be configured and can communicate
with other users in the normal state. For the configuration method, see 3.3.1 Example:
Configuring the VoIP Service (H.248-based).
l Users of the PBX must be configured and can communicate with each other in the normal
state.
l The system must be configured with the EDTB board.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
3 Configuring the DSLAM Services
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
340
