Huawei SmartAX MA5608T User Manual

ONT
Type
Prod
uct
Nam
e
User-
to-
Netwo
rk
Interfa
ce
(UNI)
Numb
er of
GEM
Ports
IP
Addre
ss
Config
ured
Capabi
lity
Numb
er of T-
CONT
s
Mappi
ng
Mode
Betwe
en
Servic
e
Stream
s and
the
GEM
Port
Flow
Contro
l Type
Numb
er of
PQs
Suppo
rted by
a T-
CONT
HG84
47
4POTS
+4GE
+USB
+RF
+WiFi
32 Support
ed
8 VLAN/
PRI/
VLAN
+PRI/
IPToS/
Port/
Port
+VLA
N/Port
+PRI/
Port
+VLA
N+PRI
PQ/
Gempor
t CAR/
Flow
CAR
4
NOTE
When flow control type GEM port CAR is used, upstream QoS does not take effect for both the HG810 and
HG810a and therefore packets are not scheduled by priority. As a result, when network congestion occurs,
packets with various priorities are not processed by priority but are dropped randomly on the HG810 or HG810a.
9.6 Principle of FTTH Data Plan
9.6.1 Data Plan Principles for IP Addresses
This section describes how to obtain an IP address in various scenarios.
Data Plan Principles for IP Addresses
Terminal
Type
Service Recommended Solution
Bridging
+Voice ONT
Internet
access
A PC obtains an IP address through PPPoE dialup. The ONT
transparently transmits the packets.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 9 FTTH Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
563

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
