Scenario Description OLT Typical
Configuration
(Main Control Board
+
Service Board
+Upstream Board)
MDU
Configuration
FTTB/
FTTC
+HGW
Networki
ng (HGW
Providin
g the
VoIP
Service)
l The ONU is deployed in
the building or street fiber
distribution terminal and
uses LAN or xDSL to
connect to the HGW
deployed at user's home.
l The HGW provides the
Internet access, IPTV,
and VoIP services by
connecting to the
upstream ONU using
LAN or xDSL. The built-
in IAD of the HGW
provides the VoIP
service.
ONUs applicable to
this scenario:
MA5616, MA5821,
MA5822,
MA5622A,
MA5623,
MA5623A,
MA5611S-AE16,
MA5611S-AE16 (No
SPL), MA5611S-
DE16, MA5611S-
DE48 (900-ohm
impedance),
MA5611S-DE48,
MA5611S-DE48-A,
MA5603T, MA5612,
MA5612A. Among
these ONUs:
l ONUs with LAN
ports include
MA5616,
MA5821,
MA5612,
MA5612A.
l ONUs with
ADSL2+ ports
include MA5616,
MA5603T.
l ONUs with
VDSL2 ports
include MA5616,
MA5622A,
MA5623,
MA5623A,
MA5611S-AE16,
MA5611S-AE16
(No SPL),
MA5611S-DE16,
MA5611S-DE48
(900-ohm
impedance),
MA5611S-DE48,
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
820

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
