Huawei SmartAX MA5608T User Manual

Scenario Description OLT Typical
Configuration
(Main Control Board
+
Service Board
+Upstream Board)
MDU
Configuration
FTTB/
FTTC
+HGW
Networki
ng (ONU
Providin
g the
VoIP
Service)
l The ONU is deployed in
the building or street fiber
distribution terminal and
uses LAN or xDSL to
connect to the HGW
deployed at user's home.
The HGW provides
service access interfaces
and the built-in IAD of
the ONU provides the
VoIP service.
l The HGW provides the
Internet access and IPTV
services by connecting to
the upstream ONU using
LAN or xDSL.
ONUs applicable to
this scenario:
MA5822, MA5616,
MA5622A,
MA5603T, MA5612.
Among these ONUs:
l ONUs with LAN
ports include
MA5616,
MA5822,
MA5612.
l ONUs with xDSL
ports include
MA5616,
MA5622A,
MA5603T.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
819

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
