Item Data
Traffic profile ID: 8
802.1p priority: 4
CIR: off (unlimited)
Priority-based scheduling policy: local-setting
VLAN Plan Single VLAN tag:
l SVLAN ID: 1100
l VLAN type: smart
l VLAN attribute: common
l UVLAN (upstream VLAN of the HGW): 43
l CVLAN=UVLAN
VLAN translation policy:
l ONU: transparently transmits the UVLAN of the HGW.
l OLT: implements VLAN translation: U<->S.
Procedure
Step 1 Configure the OLT.
1. Configure a traffic profile.
Configure traffic profile 8. Set the CIR to off (unlimited), priority to 4, and priority-based
scheduling policy to local-setting (that is, queues are scheduled based on the priority
specified in the profile).
NOTE
Run the display traffic table ip command to query the existing traffic profiles in the system. If the existing
traffic profiles in the system do not meet the requirements, run the traffic table ip command to add a
traffic profile.
huawei(config)#traffic table ip index 8 cir off priority 4 priority-policy
local-setting
2. Configure the mapping relationship between a GEM port and a VDSL2 port on the ONU.
The service flow of user VLAN 43 is mapped to GEM port 13 in the ONU line profile.
huawei(config)#ont-lineprofile gpon profile-name fttd
huawei(config-gpon-lineprofile-1)#gem mapping 13 4 vlan 43
huawei(config-gpon-lineprofile-1)#commit
huawei(config-gpon-lineprofile-1)#quit
3. Configure the VLAN of the Ethernet port on the ONU.
If the ONU is connected to the HGW through VDSL2 port 1, add VDSL2 port 1 to VLAN
43.
huawei(config)#ont-srvprofile gpon profile-name fttd
huawei(config-gpon-srvprofile-1)#port vlan vdsl 1 43
huawei(config-gpon-srvprofile-1)#commit
huawei(config-gpon-srvprofile-1)#quit
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
10 FTTD Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
780
