Remote
Service
Verificati
on
Method
Function Remarks
Multicast
emulation
This function enables you to emulate
a multicast user goes online and lead
the program stream to an ONU. By
querying the real-time traffic of the
multicast program, you can check
whether the multicast function is
performing well.
The multicast service configured in
dynamic controllable multicast mode
does not support the remote
acceptance function.
Data plan
Item Data Remarks
PPPoE
dialup
emulation
parameter
Referenced service flow ID: 101
Emulation timeout time: 10s
The entered user name, password, and
authentication mode must be
consistent with those configured on
the BRAS.
Multicast
emulation
parameter
Multicast service flow ID: 401
Multicast VLAN: 1000
IP address of the multicast program:
224.1.1.10
-
Procedure
l Verify the Internet access service using PPPoE dialup emulation.
1. Start an emulation test by running the simulate dhcp start command.
huawei(config)#pppoe simulate start
Command:
pppoe simulate start
Service-port(index<0-999>):101
User Name(length<1,65>):user0
User Password(length<0,16>):*******
Authentication Mode:
1. Chap 2. Pap [default 1]:1
Overtime Time(5-60s)[default 5]:10
2. Query the emulation test information by running the display pppoe simulate info
command.
huawei(config)#display pppoe simulate info
PPPoE simulate information is:
-----------------------------------------------------------------
Service-port: 101
User name: user0
Current phase: - //*Emulation phase
Result: Success //*Emulation result
Start time: 2011-11-16 15:41:29+08:00
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1020
