Service
Type
VLAN Plan Remarks
Multicast
service
MVLAN: 1000
IGMP version: IGMPv3
IGMP mode: IGMP
proxy
Multicast program
library: 224.1.1.10–
224.1.1.100
IP address of the
multicast server:
10.10.10.10/24
The multicast service is a carrier-operating closed
service and primarily uses only S-VLAN tags.
For details, refer to 11.2.6 Principle of IPTV
Service Data Plan.
NOTE
C-VLANs in the preceding table are defined for remote extended subracks. That is, they are upstream VLANs
or S-VLANs of HGWs.
Procedure
l Configure an Internet access service flow.
1. Create an S-VLAN and add an upstream port to it.
Create S-VLAN 100 with the stacking attribute and add upstream port 0/19/0 to the
S-VLAN.
huawei(config)#vlan 100 smart
huawei(config)#vlan attrib 100 stacking
huawei(config)#port vlan 100 0/19 0
2. Configure a traffic profile.
The 802.1p priority of the Internet access service is 0, and rate limitation is not
required. To query existing traffic profiles, run the display traffic table ip command.
In this example, the query result shows that traffic profile 6 meets the requirements,
so no traffic profile needs to be configured.
huawei(config)#display traffic table ip from-index 0
3. Configure a service port to receive and transparently transmit the Internet access
service from the HGW.
Configure an Internet access service port with the user VLAN being 1001 or 1002.
The HGW is connected to port 1/1/0 of the GE remote extended subrack. Upstream
and downstream traffic is rate-limited using a line profile. A traffic profile (traffic
profile 6 in this example) that does not limit rates is referenced.
huawei(config)#service-port vlan 100 vdsl mode ptm 1/1/0 multi-service
user-vlan 1001 rx-cttr 6 tx-cttr 6
huawei(config)#service-port vlan 100 vdsl mode ptm 1/1/0 multi-service
user-vlan 1002 rx-cttr 6 tx-cttr 6
l Configure a voice service flow.
1. Create an S-VLAN and add an upstream port to it.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1051
