Huawei SmartAX MA5608T User Manual

Parameter Value
VLAN
enabling
Enabled: Upstream packets contain VLAN tags.
Disabled: Upstream packets do not contain VLAN tags.
NOTE
If uservlan is set to untagged when you configure a service flow for
the Internet access service on the ONU, set this parameter to
Disabled; otherwise, set it to Enabled.
VLANID
[1-4094]
If VLAN enabling is set to Enabled, this parameter takes
the value of uservlan that is specified when you configure a
service flow for the Internet access service on the ONU.
Binding item LAN1 and LAN2: PCs connected to ports LAN1 and LAN2
can simultaneously access the Internet.
Mode Bridge: PCs access the Internet in PPPoE dial-up mode.
c. Click OK.
3. Restart the HGW.
Choose Management > Device Management and click Restarting the Device.
l Configure the Internet access service (on an HG527).
1. Log in to the Web configuration window.
a. Enter http://192.168.1.1/cnc.html (default IP address) to the address bar of the
IE and press Enter.
b. In the login dialog box, enter the user name (default: admin) and password
(default: admin) of the administrator. Then, click OK.
2. Set parameters for the Internet access service.
Assume that ports LAN1 and LAN2 are Internet access ports for PCs.
a. Choose Network > Bandwidth Configuration from the navigation tree.
b. Create WAN connection 1 and set parameters based on the following table.
Parameter Value
Bearing
service
INTERNET
Enabling If this parameter is selected, WAN connection 1 is used.
VPI/VCI Contact your carrier for the value ranges of VPIs and VCIs.
Ensure that the VPI/VCI setting (for example, 0/35) on an
HGW is consistent with that on the office to which the HGW
is connected.
Binding item LAN1 and LAN2: PCs connected to ports LAN1 and LAN2
can simultaneously access the Internet.
Mode Bridge: PCs access the Internet in PPPoE dialup mode.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 11 FTTB and FTTC Solution Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1064

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
