Huawei SmartAX MA5608T User Manual

Typical Networking Scenarios and Hardware Configurations
Networking
Scenario
Description Typical OLT
Configuration
ONU Device
FTTO SOHO
networking
l ONUs are deployed for
shops and markets.
l ONUs provide GE and
POTS ports. Through the
ports, the ONUs provide
the following services for
users: Internet access
through cables, Internet
access through wireless
fidelity (Wi-Fi),
broadband TV (BTV),
VoD, VoIP, fax, and point
of sale (POS).
SCUN+GPBD/
GPBH/GPFD
+GICK/X2CS
MA5671, MA5675,
and MA5675M
FTTO SME
bridging
networking
l In bridging mode, ONUs
connect to an enterprise
router through GE ports
and provide the Internet
access and VoD services
for the users connected to
the enterprise router.
l ONUs provide GE/FE and
POTS ports. Through the
ports, the ONUs provide
the BTV and VoIP
services for users.
MA5671, MA5672M,
and MA5612
FTTO SME
gateway
networking
l In gateway mode, ONUs
connect to an enterprise
LAN switch through GE
ports and provide the
Internet access and VoD
services for the users
connected to the
enterprise LAN switch.
l ONUs provide GE/FE and
POTS ports. Through the
ports, the ONUs provide
the BTV and VoIP
services for users.
MA5671, MA5672M,
and MA5612
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 12 FTTO Configuration(SOHO and SME)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1077

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
