Huawei SmartAX MA5608T User Manual

ONU
Nam
e
ONU Type Uplink
Port
User Port ONU
Version
Support
ed
Feature
and
Positionin
g
MA5
612
Gateway
type
Provides
two ports
supporting
autonegotiat
ion between
GPON, and
GE.
For the bottom plate with
POTS ports:
l Provides 2 GE
electrical ports+6 FE
electrical ports+48
POTS ports+
(optional)1 RF port
when two ASNB
boards are
configured.
l Provides 2 GE
electrical ports+22
FE electrical ports
+16 POTS ports+
(optional)1 RF port
when two EIUC
boards are
configured.
l Provides 2 GE
electrical ports+6 FE
electrical ports+16
E1/T1 ports+16
POTS ports+
(optional)1 RF
interface when two
E81A boards are
configured.
For the bottom plate
without POTS ports:
l Provides 2 GE
electrical ports+6 FE
electrical ports+32
POTS ports when
two ASNB boards are
configured.
l Provides 2 GE
electrical ports+22
FE electrical ports
when two EIUC
boards are
configured.
l Provides 2 GE
electrical ports+6 FE
V800R30
8C00
V800R30
8C01
V800R31
0C00
V800R31
1C00
V800R31
2C00
Used in SME
scenarios.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 12 FTTO Configuration(SOHO and SME)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1079

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
