Huawei SmartAX MA5608T User Manual

Plan Device/Service Description
ONU/Router Use a single-tagged S-VLAN as the management
VLAN of the router that is managed.
Set an S-VLAN for an entire network, an OLT, a
PON board or a PON port for identifying services
and physical locations. It is recommended that you
set different router management VLANs for the
OLTs connected to one SR to avoid an excessively
large broadcast domain of the SR and convergence
switch.
IP address plan
(bridging +
router
networking)
Internet access
service
As a Dynamic Host Configuration Protocol (DHCP)
client, the router obtains a public IP address through
PPPoE dialup. As a DHCP server, the router assigns
private IP addresses to PCs that access the Internet
through network cables or Wi-Fi. After Network
Address Translation (NAT), all the PCs connected
to the router use a public IP address to access the
Internet. The ONU transparently transmits service
packets.
IPTV service The router is configured with a bridging WAN port.
The STB obtains a public IP address through DHCP.
The router and the ONU transparently transmit
service packets.
VoIP service As a DHCP client, the router obtains a public IP
address through DHCP, or the ACS allocates a static
IP address to the router through TR069. The voice
signaling streams and the media streams of multiple
POTS ports share the IP address. Media streams can
be distinguished by different ports. The ONU
transparently transmits service packets.
TR069
management
(optional)
As a DHCP client, the router obtains a public IP
address through DHCP. The router connects to the
TR069 server (ACS). The ONU transparently
transmits service packets.
IP address plan
(gateway
networking)
Internet access
service
As a DHCP client, the ONU obtains a public IP
address through PPPoE dialup. As a DHCP server,
the ONU allocates private network IP addresses to
PCs that access the Internet through the network
cables or Wi-Fi. After NAT, all the PCs connected
to the router use the public IP address to access the
Internet.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 12 FTTO Configuration(SOHO and SME)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1081

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
