Data Plan
Table 12-4 Data plan
Item Data
ONU line profile Profile name: ftto_line
T-CONT ID: 4
GEM port ID for Internet access service: 14
ONU service profile Profile name: ftto_ser
ONU port capability set: adaptive
Procedure
l Configure the OLT.
1. Configure a traffic profile.
Run the display traffic table ip command to query existing traffic profiles in the
system. If the traffic profiles existing in the system do not meet the requirements, you
need to run the traffic table ip command to add a traffic profile.
Set the profile ID to ftto_hsi, the CIR to 4 Mbit/s, and the priority to 0. In addition,
configure the scheduling mode so that packets are scheduled according to their
priorities.
huawei(config)#traffic table ip name ftto_hsi cir 4096 priority 0 priority-
policy local-setting
2. Configure the mapping between a GEM port and a VLAN. Create a service VLAN
and a service flow.
Table 12-5 Scenario plan
Scenario VLAN Plan VLAN Translation Policy
gateway ONU Double-tagged
VLAN
l S-VLAN ID: 100
l S-VLAN type:
smart
l S-VLAN
attribute:
stacking
l C-VLAN ID:
1001
l C'-VLAN ID:
1010-1011
ONU: Configure a VLAN for all
ONUs and add the same C-VLAN
tag to packets. All ONUs are in the
same C-VLAN.
OLT: The OLT switches between
the C-VLAN tag and the S-VLAN
+C'-VLAN tag. All ONUs are in
different C-VLANs.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
12 FTTO Configuration(SOHO and SME)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1104
To Next Page
