Huawei SmartAX MA5608T User Manual

Table 1-24 Data plan for configuring the H801VESC
Item Data Remarks
EMU EMU ID: 2
Subnode ID: 25
The ID and subnode ID of the H801VESC cannot
conflict with those of the existing EMUs.
Digital
parameters
Digital parameter ID: 0 -
Valid level of digital
parameter 0: low level
When the low level represents the valid level, the
MA5608T does not report an alarm in the case of
low level.
Name of digital
parameter 0:
Temperature
This digital parameter is set according to the actual
requirements. The monitoring digital parameter of
the temperature sensor is set to monitor the
temperature.
Digital parameter ID: 1 -
Valid level of digital
parameter 1: low level
When the low level represents the valid level, the
MA5608T does not report an alarm in the case of
low level.
Name of digital
parameter 1: Door
This digital parameter is set according to the actual
requirements. The monitoring digital parameter of
the door sensor is set to monitor the door status.
Digital parameter ID: 2 -
Valid level of digital
parameter 2: low level
When the low level represents the valid level, the
MA5608T does not report an alarm in the case of
low level.
Name of digital
parameter 2: Arrester
This digital parameter is set according to the actual
requirements. The monitoring digital parameter of
the lightning arrester status sensor is set to monitor
the arrester status.
Digital parameter ID: 3 -
Valid level of digital
parameter 3: low level
hen the low level represents the valid level, the
MA5608T does not report an alarm in the case of
low level.
Name of digital
parameter 3: Fan
This digital parameter is set according to the actual
requirements. The monitoring digital parameter of
the fan status sensor is set to monitor the fan status.
NOTE
The enhanced heat dissipation module is an optional
module. The fan monitoring digital parameter is required
only when the enhanced heat dissipation module is
configured. Otherwise, the system will report an alarm.
huawei(config)#emu add 2 H801VESC 0 25 H801VESC
huawei(config)#display emu 2
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
1 Commissioning
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
88

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
