l The ONU has been added to the OLT. For details, see 12.3.3 Adding an ONU to an
OLT.
l Different voice services require different ONU software versions. Before the configuration,
ensure that the ONU software version supports H.248. For details, see relevant ONU
manuals.
Context
Table 12-8 Data plan
Item Data
ONU line profile Profile name: ftto_line
T-CONT ID: 4
GEM port ID: 12
ONU service profile Profile name: ftto_ser
ONU port capability set: adaptive
Networking data IP address of the MGC server: 200.200.200.200/24
Port ID of the MGC server: 2944
Procedure
Step 1 Configure a traffic profile.
Set the profile name to ftto_voip and do not limit the upstream and downstream rates. Set the
priority to 5 and packets are scheduled according to the priority carried.
Run the display traffic table ip command to query existing traffic profiles in the system. If the
existing traffic profiles in the system do not meet the requirements, run the traffic table ip
command to add a traffic profile.
Step 2 Configure the mapping between a GEM port and a VLAN. Create a service VLAN and a service
flow.
Table 12-9 Scenario plan
Scenario VLAN Plan VLAN Translation Policy
Scenario 1 Single VLAN tag
l S-VLAN ID: 300
l S-VLAN type: smart
l S-VLAN attribute: common
l C-VLAN ID: 300
ONU: Configure a VLAN for all
ONUs and add the same C-
VLAN tag to packets. All ONUs
are in the same C-VLAN.
OLT: The OLT transparently
transmits VLAN tags (the C-
VLAN is the same as the planned
S-VLAN).
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 12 FTTO Configuration(SOHO and SME)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1115
