c. On the login window, enter the user name (default: telecomadmin) and password
(default: admintelecom) of the administrator. After the password authentication
is passed, the Web configuration interface is displayed.
2. Configure parameters of a voice WAN port.
a. In the navigation tree, choose WAN > WAN Configuration.
b. In the right pane, click New. In the dialog box that is displayed, configure
parameters of a WAN port as follows:
– WAN Connection: Enable
– Service List: VoIP (For configuring the VoIP service, VoIP or a combination
containing VoIP needs to be selected.)
– Mode: Route
– VLAN ID: 300 (The VLAN ID of the ONU must be the same as the user-side
VLAN ID configured on the OLT.)
– 802.1p: 5
– IP Acquisition Mode: DHCP
c. Click Apply to apply the configuration.
3. Configure parameters of the SIP-based voice interface.
a. In the navigation tree, choose Voice > VoIP Basic Configuration.
b. In the right pane, configure parameters of the SIP-based voice interface as follows
(other parameters use the default settings):
– Set Proxy Server Address below Primary Server to 200.200.200.200.
– Home Domain: softx3000.huawei.com
– Signaling Port: 1_VOIP_R_VID_300
– Region: China
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
12 FTTO Configuration(SOHO and SME)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1122
