Item Data
ONU line profile Profile name: ftto_line
T-CONT ID: 4
GEM port ID for management services: 11
GEM port ID for voice services: 12
GEM port ID for video services: 13
GEM port ID for Internet access services: 14
ONU service
profile
Profile name: ftto_ser
ONU port capability set: adaptive
Network
topology data
PON port: 0/1/0
ONU IDs: 1 and 2
Procedure
Step 1 Configure GPON ONU profiles.
GPON ONU profiles include the DBA profile, line profile, service profile, and alarm profile.
l DBA profile: A DBA profile describes GPON traffic parameters. A T-CONT is bound to a
DBA profile for dynamic bandwidth allocation, improving upstream bandwidth utilization.
l Line profile: A line profile describes the binding between the T-CONT and the DBA profile,
the QoS mode of the traffic stream, and the mapping between the GEM port and the ONU-
side service.
l Service profile: A service profile provides the service configuration channel for the ONU
that is managed by using optical network terminal management and control interface
(OMCI).
l Alarm profile: An alarm profile contains a series of alarm thresholds to measure and monitor
the performance of activated ONU lines. When a statistical value reaches the threshold, the
host is notified and an alarm is reported to the log host and the NMS.
1. Configure a DBA profile.
Run the display dba-profile command to query existing DBA profiles in the system. If the
existing DBA profiles in the system do not meet the requirements, run the dba-profile
add command to add a DBA profile.
Create the same DBA profile for different types of services. Set the profile name to
ftto_dba, profile type to type3, assured bandwidth to 8 Mbit/s, and maximum bandwidth
to 50 Mbit/s.
huawei(config)#dba-profile add profile-name ftto_dba type3 assure 8192 max
51200
NOTE
The DBA implementation is based on an ONU. Therefore, select a DBA profile of the proper bandwidth
type and configure proper bandwidth according to the service types and total user count of the ONU. Note
that the sum of the fixed bandwidth and the assured bandwidth must not be greater than the total bandwidth
of the PON port.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
12 FTTO Configuration(SOHO and SME)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1147
