Item Data
Traffic profile ID: 8
802.1p priority: 4
CIR: off (unlimited)
Priority-based scheduling policy: local-setting
Procedure
Step 1 Configure the OLT.
1. Configure a traffic profile.
Configure traffic profile 8. Set the CIR to off (unlimited), priority to 4, and priority-based
scheduling policy to local-setting (that is, queues are scheduled based on the priority
specified in the profile).
NOTE
Run the display traffic table ip command to query existing traffic profiles in the system. If the existing
traffic profiles in the system do not meet the requirements, run the traffic table ip command to add a
traffic profile.
huawei(config)#traffic table ip index 8 cir off priority 4 priority-policy
local-setting
2. Perform this step in the bridging ONU+router (single VLAN tag) scenario.
Table 12-32 Data plan
VLAN Plan VLAN Translation Policy
l S-VLAN ID: 1100
l VLAN type: smart
l VLAN attribute: common
l C-VLAN = U-VLAN
The ONU adds the default C-VLAN tag to
packets from iTV service ports.
The OLT transparently transmits S-VLAN
tags.
Configure the mapping between a GEM port and a VLAN. The service flow of user VLAN
1100 is mapped to GEM port 13 in the ONU line profile.
huawei(config)#ont-lineprofile gpon profile-name ftto_line
huawei(config-gpon-lineprofile-1)#gem mapping 13 4 vlan 1100
huawei(config-gpon-lineprofile-1)#commit
huawei(config-gpon-lineprofile-1)#quit
Configure the VLAN of the Ethernet port on the ONU. If the ONU is connected to the STB
through Ethernet port 2, add Ethernet port 2 to VLAN 1100.
huawei(config)#ont-srvprofile gpon profile-name ftto_ser
huawei(config-gpon-srvprofile-1)#port vlan eth 2 1100
huawei(config-gpon-srvprofile-1)#commit
huawei(config-gpon-srvprofile-1)#quit
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
12 FTTO Configuration(SOHO and SME)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1178
