Huawei SmartAX MA5608T User Manual

Monitoring
Parameter
Displayed on
the Host
Device Port Application in the N66
Cabinet
Application in the
F01D500 Cabinet
Digital 4 JTD5 Not connected by default,
used to add a user-defined
monitoring digital
parameter
Smoke sensor
Digital 5 JTD6 Not connected by default,
used to add a user-defined
monitoring digital
parameter
Heat exchanger
Digital 6 JTD7 Not connected by default,
used to add a user-defined
monitoring digital
parameter
Door status sensor of
the MDF compartment
Door alarm JTM1
Not connected by default,
used to monitor a door
status sensor
Door status sensors of
the device compartment
and heat exchanger
compartment
Wiring alarm JTP1 Not connected by default,
used to monitor a MDF
sensor
MDF
Battery Tem BAT_WE Battery temperature sensor Battery temperature
sensor
environment
Tem/environment
Hum
TEM-HU Not connected by default. Temperature and
humidity sensor
NOTE
Before adding a user-defined analog or monitoring digital parameter, make sure that the port corresponding
to this parameter is properly connected to an environment monitoring cable.
Configuration Process
The monitoring parameters can be reported to the control system only when the data for the
EPS75-4815AF is configured correctly in the system.
Table 1-29 lists the commands used during the configuration.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
1 Commissioning
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
96

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
