Enterprise PRA PBX Access
Parameter Value
Traffic
classification,
marking, and
scheduling policies
802.1p priority 5
Queue scheduling
mode
PQ
OLT queue ID
(eight queues)
5
Traffic
monitorin
g and
DBA
policies
OLT T-CONT (only for
GPON)
All services share one T-CONT.
DBA type Type 3 ("Assured bandwidth+maximum
bandwidth" DBA profile. This type of DBA not
only ensures a fixed bandwidth for users but also
enables users to preempt a certain amount of
bandwidth, but the total bandwidth cannot
exceed the maximum bandwidth.)
DBA bandwidth DBA bandwidth is configured based on the
bandwidth package selected by the user.
The assured bandwidth is the maximum
bandwidth required for transmitting
management packets and VoIP service packets.
The maximum bandwidth is equal to or higher
than the maximum bandwidth applied by the
user.
Downstream traffic
profile
Downstream traffic rate is not limited.
ONU Upstream port rate
limit
Set this parameter based on requirements.
Downstream port
rate limit
Set this parameter based on requirements.
Enterprise IP PBX Access
The QoS policies for this scenario are the same as those for the Layer 2 interoperation Between
Different Enterprise Branches scenario.
Enterprise E1/T1 unified access
In this scenario, ONUs access services through E1/T1 lines. Therefore, the QoS policies are
mainly planned for traffic on PON lines.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
13 FTTO Configuration (Large-sized Enterprise Access)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1262
