l An ONU can be added in two modes: offline addition and online confirmation. Select either
mode as required.
Data Plan
Table 13-4 Key data plan
Configurati
on Item
Data
DBA profile DBA profile for management service: dba-profile_1 (system default)
DBA profile for private line service:
l Profile ID: 21
l Profile type: Fixed bandwidth and minimum delay
l DBA bandwidth: 28928 kbit/s (Each ONU accesses four E1 private lines
and each line has a recommended DBA bandwidth of 7232 kbit/s.)
Line profile Profile ID: 11
T-CONT ID: 1 (for private line service) and 2 (for management service)
GEM port ID for management service: 11
GEM port ID for DDN private line service: 13
Networking
data
PON port: 0/3/1
ONU parameters:
l ONU ID: 1
l SN: 32303131B39FD641
Procedure
Step 1 Configure GPON ONU profiles.
1. Configure a DBA profile. Enable the bandwidth compensation function and set the DBA
bandwidth allocation mode for the GPON port to minimum bandwidth delay.
huawei(config)#dba-profile add profile-id 21 type1 fix 28928
bandwidth_compensate yes
huawei(config)#interface gpon 0/3
huawei(config-if-gpon-0/3)#port dba bandwidth-assignment-mode 1 min-loop-delay
huawei(config-if-gpon-0/3)#quit
2. Configure an ONU line profile.
huawei(config)#ont-lineprofile gpon profile-id 11
huawei(config-gpon-lineprofile-11)#tcont 1 dba-profile-id 21 //Bind T-CONT 1
to DBA profile 21
huawei(config-gpon-lineprofile-11)#tcont 2 dba-profile-id 1 //Bind T-CONT 2
to DBA profile 1
huawei(config-gpon-lineprofile-11)#gem add 11 eth tcont 2
huawei(config-gpon-lineprofile-11)#gem add 13 tdm tcont 1 //Add GEM port 13 to
T-CONT 1.
huawei(config-gpon-lineprofile-11)#gem mapping 11 0 vlan 8
huawei(config-gpon-lineprofile-11)#gem mapping 13 1 e1 1 //Map GEM port 13 to
E1 port 1 on the ONU.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
13 FTTO Configuration (Large-sized Enterprise Access)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1290

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
