Huawei SmartAX MA5608T User Manual

Item Data Plan for the F01S300 Cabinet
Battery
management
parameters
Current-limiting coefficient for battery charging:
l One 50 AH battery set: 0.15
l One 92 AH battery set: 0.1
Interval of battery equalized charging (day): 60
Number of battery sets: 1
Capacity of the battery set:
l One 50 AH battery set: 50
l One 92 AH battery set: 92
The upper/lower
temperature test
limits or
temperature
compensation
coefficient of the
battery set
Upper temperature threshold of the battery set (°C): 80
Lower temperature threshold of the battery set (°C): -20
Temperature compensation coefficient of the battery set (mV): 80
The upper/lower
temperature alarm
limits of the battery
set
Upper temperature alarm limit of the battery set (°C): 50
Lower temperature alarm limit of the battery set (°C): -15
Battery discharging
test parameters
Battery auto-discharging test: auto-test
Battery set auto-discharging test permission status: permit
Battery auto-discharging test period (day): 120
Load power-off and
battery set power-
off voltage
parameters
Battery set power-off permission status: permit
Battery set power-off voltage (V): 43
Battery high-
temperature power-
off parameters
Battery high-temperature power-off permission status: permit
Temperature for battery high-temperature power-off (°C): 53
Environment
temperature
parameters
Upper alarm threshold of the temperature (°C): 68
Lower alarm threshold of the temperature (°C): -20
Upper test threshold of the temperature (°C): 80
Lower test threshold of the temperature (°C): -20
Environment
humidity
parameters
Upper alarm threshold of the humidity (% RH): 80
Lower alarm threshold of the humidity (% RH): 0
Upper test threshold of the humidity (% RH): 100
Lower test threshold of the humidity (% RH): 0
Power rectifier
module parameters
The number of the power rectifier modules is configured according to
the actual value. ETP4830 supports up to 2 rectifier modules.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 1 Commissioning
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
112

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
