Data Plan
Table 13-12 Key data plan
Item Data
DBA profile Profile ID: 20
Profile type: Fixed bandwidth and minimum delay
DBA bandwidth:
l E1 access: 32 Mbit/s is recommended. (Each ONU accesses four E1
private lines and each line has a recommended DBA bandwidth of 8 Mbit/
s)
l T1 access: 24 Mbit/s is recommended. (Each ONU accesses four T1
private lines and each line has a recommended DBA bandwidth of 6 Mbit/
s)
Line profile Profile ID: 10
T-CONT ID: 1
GEM port ID for management service: 11
GEM port ID for DDN private line service: 12
Networking
data
PON port: 0/3/1
ONU parameters:
l ONU ID: 1
l SN: 32303131B39FD641
Procedure
Step 1 Configure GPON ONU profiles.
1. Configure a DBA profile. and set the DBA bandwidth allocation mode for the GPON port
to minimum bandwidth delay.
For example, configure the DBA profile for 4-channel E1 private line.
huawei(config)#dba-profile add profile-id 20 type1 fix 32768
huawei(config)#interface gpon 0/3
huawei(config-if-gpon-0/3)#port dba bandwidth-assignment-mode 1 min-loop-delay
huawei(config-if-gpon-0/3)#quit
2. Configure an ONU line profile.
huawei(config)#ont-lineprofile gpon profile-id 10
huawei(config-gpon-lineprofile-10)#tcont 1 dba-profile-id 20 //Bind T-CONT 1
to DBA profile 20
huawei(config-gpon-lineprofile-10)#gem add 11 eth tcont 0
huawei(config-gpon-lineprofile-10)#gem add 12 eth tcont 1 //Add GEM port 12 to
T-CONT 1
huawei(config-gpon-lineprofile-10)#gem mapping 11 0 vlan 8
huawei(config-gpon-lineprofile-10)#gem mapping 12 1 vlan 300 //Map GEM port 12
to CVLAN 300
huawei(config-gpon-lineprofile-10)#commit
huawei(config-gpon-lineprofile-10)#quit
3. (Optional) Configure an alarm profile.
