Procedure
l Add a remote extended frame in offline mode.
huawei(config)#frame add 1 MA5633 extending-port 0/3/1 sn 48575443E6D8B541
NOTE
When running the frame add command to add a remote extended frame in offline mode, the OLT
automatically allocates a temporary SN for the remote extended frame. Therefore, you do not need to
specify the SN of the remote extended frame. After obtaining the SN of the remote extended frame, run
the frame bind command to add the binding relationship between the SN and the remote extended frame
to the OLT. Then the remote extended frame is added.
l Add an automatically discovered remote extended frame.
The OLT supports the adding of an automatically discovered GPON remote extended
frame. This function does not require manual confirmation, thereby simplifying the remote
extended frame registration and adding flow.
huawei(config)#interface gpon 0/3
huawei(config-if-gpon-0/3)#port 1 ont-auto-find enable
huawei(config-if-gpon-0/3)#quit
----End
Result
The remote extended frame is online.
After adding the remote extended frame, run the display frame info command to query the
status of the remote extended frame. Ensure that Online state is online and State is normal.
huawei(config)#display frame info 1
--------------------------------------------------------------------------
Type: MA5633
State: Normal
Desc: MA5633_1_extending_0/3/1/1
Hardware: MA5633
Extend type: GPON
Extending port: 0 /3 /1
ONT ID: 1
ONT SN: 48575443E6D8B541
Extended port: 1 /0 /1
Online state: Online
Optical-receiver: Offline
--------------------------------------------------------------------------
Follow-up Procedure
If the remote extended frame cannot be discovered, follow the troubleshooting suggestions listed
in the following table to rectify faults.
Possible Cause Troubleshooting Suggestion
The MA5633 automatic
discovery function is disabled.
In GPON mode, run the port ont-auto-find command to
enable the MA5633 automatic discovery function on GPON
ports.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
15 OptiCable D-CMTS Configuration (MA5633 Working as
a Remote Extended Frame)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1551

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
