Huawei SmartAX MA5608T User Manual

1. Run the simulate dhcp start cm mac-address [ option60 option60 ] command to start
a DHCP dialup emulation test.
NOTE
You can run the simulate dhcp stop command to stop the DHCP emulation.
2. Run the display simulation dhcp command to query the results of the DHCP dialup
emulation test.
3. Check whether the User IP has obtained an IP address.
l Check the CM status.
Run the display cable modem command to query the CM status in Status.
huawei(config)#display cable modem all
------------------------------------------------------------------------------
-
Idx MAC IP I/F Status Prim Num Ver DS
RX
SID CPE
Power
------------------------------------------------------------------------------
-
1 0023-ED6F-21A3 192.168.1.118 1/1/0/U4 ol-pt 1 0 D2.0
-
------------------------------------------------------------------------------
-
Total:
1
ol: 0, ol-ptd: 0, ol-pt: 1, ol-d: 0, wol: 0, wol-ptd: 0, wol-pt: 0, wol-d:
0,
pol: 0, pol-ptd: 0, pol-pt: 0, pol-d: 0, offline: 0, rej-m: 0, rej-pt: 0, rej-
o:
0, init: 0, init-rc: 0, DHCP: 0, DHCP-O: 0, DHCP-R: 0, DHCP-C: 0, REG:
0
Note: 1. Idx is the index of a
CM.
2. The downstream received power is in the unit of
dBmV.
3. In status, "ol" means online, "rej" means reject.
The following table lists the CM status and handling suggestions.
CM
Status
Description Handling Suggestion
init Indicates that the CM initialization
ranging message is received.the
CM initialization.
If a CM is always in the ranging state,
the ranging fails. Then check radio
frequency (RF) line indicators and
detect line faults.
init-rc Indicates that the CM initialization
ranging is complete.
No action is required. The ranging of
the CM is complete.
DHCP Indicates that the DHCP discovery
from the CM is received.
If a CM initiates a DHCP request but
does not obtain an IP address, check the
DHCP server, routing between the
OLT and the DHCP server, and DHCP
server parameter settings.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
15 OptiCable D-CMTS Configuration (MA5633 Working as
a Remote Extended Frame)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1658

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
