Parameter Default
Digital parameters ESC digital parameter IDs
l Allocated by default (unable to be changed by the user)
– 0: MDF
– 1: door status sensor 0
– 9: water
– 10-13: lightning arresters 0-3
– 14-15: switches 11 and 12
– 16-17: switches 21 and 22
– 18-19: switches 31 and 32
– 20-21: switches 41 and 42
– 22: external sensor power
l User-defined IDs
– 2-8: allocated to other extended digital sensors.
Definition of user-defined alarm indexes
1: AC voltage; 2: AC switch; 3: battery voltage; 4: battery fuse; 5: load
fuse; 6: rectifier unit; 7: secondary power supply; 8: door status of the
cabinet; 9: door status of the equipment room; 10: window; 11: theft;
12: MDF; 13: fan; 14: fire; 15: smoke; 16: water; 17: diesel; 18:
abnormal smell 19: air conditioner; 20: lightning arrester; 21: user-
defined alarms of digital parameters
Table 1-71 Default settings of the FAN
Parameter Default
Sub-node 1
Fan speed
adjustment mode
Automatic
Whether to report
the fan alarm
Permit
Table 1-72 Default settings of the TCU
Parameter Default
Sub-node 7
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 1 Commissioning
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
