According to service requirement, the user access rate is 2048 kbit/s. The query result shows
that traffic profile 5 meets the requirement.
NOTE
l If no traffic profile in the system meets the service requirement, run the traffic table ip command to
configure a new traffic profile.
l On the MA5600T/MA5603T/MA5608T, the user access rate can be limited by either a traffic profile
or an ADSL line profile. When both profiles are configured, the user bandwidth adopts the minimum
value in the two profiles. In this example, the traffic profile is used to limit the user access rate.
4. Run the service-port command to create a service port. The index of the new service port
is 1, the access port is port 0/2/0, traffic profile 5 meets the service requirement, and the S-
VLAN is VLAN 50. The VPI and VCI must be the same as the management VPI and VCI
of the peer modem. Assume that the management VPI and VCI of the modem are 1 and
39. To facilitate the maintenance of the service port, also configure the service port
description.
huawei(config)#service-port 1 vlan 50 adsl 0/2/0 vpi 1 vci 39 inbound traffic-
table
index 5 outbound traffic-table index 5
huawei(config)#service-port desc 1 description MA5600T/MA5603T/MA5608THW/
Vlanid:50/adsl/smart
5. Set the maximum number of MAC addresses that can be learned by the service port is 16.
This parameter is to limit the maximum number of the MAC addresses that can be learned
by one account, namely the maximum number of the PCs that can access the Internet
through one account.
huawei(config)#mac-address max-mac-count service-port 1 16
Step 4 In the case of the SHDSL access mode, follow this procedure.
1. Configure an SHDSL profile. For details, see Configuring SHDSL Profiles. The ID of
the SHDSL line profile is 3, the line rate is 2048 kbit/s, and the profile is used to activate
4-wire ports.
huawei(config)#shdsl line-profile quickadd 3 line four-wire rate 2048
2. Activate the SHDSL port. The port is port 0/3/1, and SHDSL line profile 3 and the default
alarm profile (alarm profile 1) are bound to the port.
NOTE
By default, an ADSL port is in the activated state. Before binding a template to the port, you must deactivate
the port.
huawei(config)#interface shl 0/3
huawei(config-if-shl-0/3)#deactivate 1
huawei(config-if-shl-0/3)#activate 1 3
huawei(config-if-shl-0/3)#alarm-config 1 1
huawei(config-if-shl-0/3)#quit
3. Run the display traffic table ip command to query the traffic profiles that exist in the
system.
huawei(config)#display traffic table ip from-index 0
{ <cr>|to-index<K> }:
Command:
display traffic table ip from-index 0
---------------------------------------------------------------------------
TID CIR CBS PIR PBS Pri Copy-policy Pri-Policy
(kbps) (bytes) (kbps) (bytes)
---------------------------------------------------------------------------
0 1024 34768 2048 69536 6 - tag-pri
1 2496 81872 4992 163744 6 - tag-pri
2 512 18384 1024 36768 0 - tag-pri
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
3 Configuring the DSLAM Services
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
269
