huawei(config)#service-port 2 vlan 50 shdsl mode atm 0/3/1 vpi 1 vci 39 inbound
traffic-table
index 5 outbound traffic-table index 5
huawei(config)#service-port desc 2 description MA5600T/MA5603T/MA5608THW/
Vlanid:50/shdsl/smart
5. Set the maximum number of MAC addresses that can be learned by the service port is 16.
This parameter is to limit the maximum number of the MAC addresses that can be learned
by one account, namely the maximum number of the PCs that can access the Internet
through one account.
huawei(config)#mac-address max-mac-count service-port 2 16
Step 5 In the case of the VDSL access mode, follow this procedure.
In this example, the VDSL normal mode is used as an example.
1. Configure a VDSL profile. For details, see Configuring VDSL2 Templates and
Profiles. Assume that the VDSL profile ID is 3, downstream rate is 2048 kbit/s, channel
mode is the interleave mode, maximum downstream interleave delay is 8 ms, maximum
upstream interleave delay is 2 ms, SNR margin is 6 dB, minimum downstream INP is 4,
and minimum upstream INP is 2.
huawei(config)#vdsl line-profile quickadd 3 snr 60 0 300 60 0 300
huawei(config)#vdsl channel-profile quickadd 3 path-mode atm interleaved-delay
8 2 inp 4 2 rate
128 10000 128 10000 2048 2048
huawei(config)#vdsl line-template quickadd 3 line 3 channel1 3 100 100
2. Activate the VDSL port. The access port is port 0/4/1, and VDSL line template 3 and the
default VDSL alarm template (alarm template 1) are bound to the port.
NOTE
By default, an ADSL port is in the activated state. Before binding a template to the port, you must deactivate
the port.
huawei(config)#interface vdsl 0/4
huawei(config-if-vdsl-0/4)#deactivate 1
huawei(config-if-vdsl-0/4)#activate 1 template-index 3
huawei(config-if-vdsl-0/4)#alarm-config 1 1
huawei(config-if-vdsl-0/4)#quit
3. Run the display traffic table ip command to query the traffic profiles that exist in the
system.
huawei(config)#display traffic table ip from-index 0
{ <cr>|to-index<K> }:
Command:
display traffic table ip from-index 0
---------------------------------------------------------------------------
TID CIR CBS PIR PBS Pri Copy-policy Pri-Policy
(kbps) (bytes) (kbps) (bytes)
---------------------------------------------------------------------------
0 1024 34768 2048 69536 6 - tag-pri
1 2496 81872 4992 163744 6 - tag-pri
2 512 18384 1024 36768 0 - tag-pri
3 576 20432 1152 40864 2 - tag-pri
4 64 4048 128 8096 4 - tag-pri
5 2048 67536 4096 135072 0 - tag-pri
6 off off off off 0 - tag-pri
---------------------------------------------------------------------------
Total Num : 7
According to service requirement, the user access rate is 2048 kbit/s. The query result shows
that traffic profile 5 meets the requirement.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
3 Configuring the DSLAM Services
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
277
