Item Data
Transmission
mode of the SIP
interface
UDP
The transmission mode is selected
according to the requirements on the
softswitch. Generally, UDP is adopted.
Home domain of
the SIP interface
huawei
Index of the
profile used by the
SIP interface
(optional)
1
VoIP user data
(The data
configuration
must be the
same as the data
configuration
on the IMS.)
Slots that the boards reside in
Voice service board (ASPB)
User access is implemented by the
ASPB board in slot 0/2, 0/3.
PSTN user
data in slot
0/2
Numbers of Phone
0-Phone 63
83110000-83110063
User priority Phone 0: Cat2; Phone 1-Phone 63: Cat3
(default)
User
authentication
PSTN user whose port is 0/2/0, and
telephone number is 83110000.
l Username: user83110000
l Password: password mode, value:
pwd83110000
PSTN user
data in slot
0/3
Numbers of Phone
64-Phone 127
88110000-88110063
User type Payphone
PSTN port
attributes
Polarity reversal pulse supported
Figure 3-11 shows an example network of the VoIP PSTN service (SIP).
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 3 Configuring the DSLAM Services
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
318
